Media Converter 10 100m 20KM Wdm Single Fiber Ethernet
Ethernet media converters are designed to transmit and receive 10/100/1000 Mbps data over single mode optical fiber. The electrical interface will Auto-Negotiate to a 10 Mbps, or 100 Mbps Ethernet rate without any adjustments. The optical interface operates at a 100 Mbps Ethernet rate. LED indicators are provided for rapidly ascertaining equipment operating status.
1. Plug and play, high performance, Low power consumption
2. Card-type or stand-alone, apply in centralized management 2U aluminum chassis
3. Cache is 512KB, MAC address table is 4KB
4. Complies with IEEE802.3 (10BASE-T) and IEEE802.3u (100BASE-TX/FX) standards
5. . Electrical port supports Auto-Negotiation for 10 Mbps or 100 Mbps, full duplex or half duplex data.
6. Automatic MDI/MDI-X crossover
7. Distances up to: 20 km Single Mode
8. SC optical connectors.
9. AC/DC powered
10. Status LED’s for TX,FX LINK/ACT, POWER,100M to easily monitor network status
11. CE approved
