Item |
Unit |
Parameters |
Remark |
Input optical wavelength |
nm |
1100-1600 |
|
Output port |
|
Four output |
|
Operation bandwidth |
MHz |
47~1000 |
|
Optical connector |
|
FC/APC or SC/APC |
|
Optical power receiving range |
dBm |
-8~+2(-3dBm is better) |
|
Reflection loss |
dB |
≥60 |
|
Flatness In band |
dB |
±0.75dB |
|
Output level |
dBμν |
≥112 |
|
C/N |
dB |
≥51 |
|
CTB |
dB |
-66 |
|
CSO |
dB |
-63 |
|
Output reflection loss |
dB |
≥16(47-550MHz) ≥14(550-1000MHz) |
|
Output Impedance |
Ω |
75 |
|
Input Voltage Range |
V |
AC110~260 or 35~70 |
|
Power Consumption |
W |
Four output:17~20 |
|
Dimension |
mm |
Four output:330×230×130 |
