FTTH Fiber Optic 60mm SC UPC Fast Connector for Drop Cable conector fibra optical
Fiber optic fast connector: A high performance, easy to use mechanical fiber optic connector. It can be widely used in FTTH drop cable connection and inter-connection. It has the same connection performance as the standard SC connector,and can be connected directly to the standard SC adapter.
Category | Specification |
Aoolicable For | Drop cable. Indoor cable |
Fiber Mode | Single mode or Multi mode |
Operation Time | About 50S(no fiber cut) |
Insertion Loss | ≤0.5dB |
Insertion Loss Typical Value | 0.3dB |
Return Loss | ≥50dB |
Fastening Strength Of Naked Fiber | ≥5N |
Tensile Strength | ≥50N |
Reusable | ≥10 times |
Operating Temperature | -40 ~ +85 ℃ |
On-line Tensile Strength(20N) | ΔIL≤0.3dB |
Mechanical Durability(500 times) | ΔIL≤0.3 |
Drop-off test(drop-off height4m,once per direction,totally 3 times) | ΔIL≤0.3 |
